Application and Features:
- Suitable for butt welding of plastic pipes and fittings made of PE, PP and PVDF in a ditch in worksite or workshop.
- Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool & heating plate, and optional parts.
- Removable PTFE coated heating plate with high accurate temperature control system.
- Electric planing tool with safety limit switch.
- Be made of lightweight and high strength material; Specially designed with a clamp opening angle of 45°.
- Low starting pressure ensures reliable welding quality of small pipes.
- High accurate and shockproof pressure meter indicates clearer readings.
- Changeable welding position enables to weld various fittings more easily.
- Separate two-channel timer records time in soaking and cooling phases.
Optional parts:
- Stub end device for short flange.
- Crane.
- Data logger.
- Trolley
Technical Parameters:
| Model | A2SHDS200 |
| Pipe size(mm) | 200,225,250,280,315,355,400,450 |
| Heating plate max. temp. | 270â |
| Temp. deviation in surface(170~250â) | ≤±7â |
| Pressure adjustable Ranges | 0-6.3Mpa |
| Working voltage | 380Vă50Hz |
| Heating plate power | 5.38KW |
| 1.5KW | 1.5KW |
| Hydraulic unit power | 1.5KW |
